Specification
| Prints | |
| Print Method | Thermal Transfer / Direct Thermal |
| Print Speed | 2-6 Inch/s (51-152 mm/s) |
| Interface | USB + Parallel + Serial |
| Print Resolution | 203 dpi |
| Dot Size | 0.125 x 0.125 mm (1 mm = 8 dots) |
| Print Width | 104 mm (4.09″) or 108 mm (4.25″) |
| Print Length | 2286 mm (90″) |
| Emulation | TSPL |
Recommended Applications
|
|
|
|
|
|
|
|
|
|
General
| Printer Dimensions | 278 x 210 x 180 mm (W x D x H) |
| Printer Weight | 2.09 Kg |
| Operation Condition | Temperature: 5~45° C (41~104° F),Humidity: 25~85%RH |
| Storage Condition | Temperature: -10~50° C (-10~104° F), Humidity: 10~90%RH |
| Pulse Excitation | 1 x 108 Pulses |
| Print Head | 50 KM |
| Power Supply | Input: AC 110V/240V Output: DC24V/2.5A, 60W |
Ribbon
| Ribbon OD | Max. 67 mm |
| Ribbon Length | Max. 300 m |
| Ribbon Core Size | 1 inch (25.4 mm) |
| Ribbon Width | Max. 110 mm, Min. 30 mm |
| Ribbon Rolling method | Outward Rolling |
Media
| Media Roll OD | 127 mm (5″) |
| Media Type | Continuous, Black Mark, Gap, Punched Hole, Fan fold labels etc. |
| Media Rolling method | Printing side outward rolling |
| Media Width | Max. 120 mm (4.72″) Min. 20 mm (0.78″) |
| Media Thickness | Max. 0.254 mm (10 mil) Min. 0.06 mm (2.36 mil) |
| Media Roll Core size | 25.4 mm~38 mm (1~1.5″) |
| Media Gap | Min. 2 mm (0.09″) |
| Label Length | 10~2286 mm (0.39″~90″) |
Contents of Package
| Driver / Software | Windows Driver and Nicelabel® SE / Labelshop® |
| Others | Sample Label, Thermal Ribbon, Driver CD, |
| USB Cable, Power Adapter. |
